Sound Library
Electrical Inspection | Example 1
- Type of partial discharge: Tracking on an insulator
- Characteristics: Discharge peaks, usually at irregular intervals | "Crackling" background noise and other irregular "popping" sounds
- Equipment: SONAPHONE with airborne sound sensor BS10
Electrical Inspection | Example 2
- Type of partial discharge: Corona on an insulator
- Characteristics: Crackling sound that is uniform
- Equipment: SONAPHONE with airborne sound sensor BS10
Electrical Inspection | Example 3
- Type of partial discharge: Arcing
- Characteristics: Short and striking bursting noises
- Equipment: SONAPHONE with airborne sound sensor BS10
Electrical Inspection | Example 4
- Type of partial discharge: Corona on a control cabinet
- Characteristics: Crackling sound that is uniform
- Equipment: SONAPHONE with airborne sound sensor BS10
Electrical Inspection | Example 5
- Type of partial discharge: Corona on an insulator
- Characteristics: Crackling sound that is uniform
- Equipment: SONAPHONE with parabolic sensor BS30
- Distance: <20 meters
![Sound Library Electrical Inspection Sound Library Electrical Inspection](/fileadmin/_processed_/c/3/csm_soundlibrary-electrical-inspection-5_b5aa522659.jpg)
![Ultrasonic Electrical Inspection: Sound Sample 5 Ultrasonic Electrical Inspection: Sound Sample 5](/fileadmin/_processed_/e/f/csm_ultrasonic_electrical_inspection__sound_sample_5_0047290f32.png)
Electrical Inspection | Example 6
- Type of partial discharge: Tracking on an insulator
- Characteristics: Discharge peaks, usually at irregular intervals
- Equipment: SONAPHONE with parabolic sensor BS30
- Distance: 10 meters
Comparison of 2 Bearings | Example 1
- Bearing comparison on 2 pumps (same bearings / same load / same manufacturer)
- Equipment: SONAPHONE and BS20 with long waveguide
- Recorded at the grease zerp
- Bearing failure at bearing 1
Comparison of 2 Bearings | Example 2
- Bearing comparison on 2 pumps (same bearings / same load / same manufacturer)
- Equipment: SONAPHONE and BS20 with long waveguide
- Recorded at the grease zerp
- Bearing failure at bearing 1
Float Steam Trap (Mechanical Steam Trap): Faulty | Intact | Example 1
- Comparison of two bimetallic steam traps (same pressure / same type / same manufacturer)
- Equipment: SONAPHONE and BS20 with long waveguide
- Trap 1: faulty
- Trap 2: intact
![Steam Trap Inspection: Sound Example 1 | Floating Steam Trap 1 | Defect Steam Trap Inspection: Sound Example 1 | Floating Steam Trap 1 | Defect](/fileadmin/_processed_/c/f/csm_steam_trap_inspection__sound_example_1___floating_steam_trap_1___defect_11670522c6.png)
![Steam Trap Inspection: Sound Example 1 | Floating Steam Trap 2 | Working Properly Steam Trap Inspection: Sound Example 1 | Floating Steam Trap 2 | Working Properly](/fileadmin/_processed_/2/5/csm_steam_trap_inspection__sound_example_1___floating_steam_trap_2___working_properly_1bef3e8141.png)
Bimetallic Steam Trap: Faulty | Intact | Example 2
- Comparison of two bimetallic steam traps (same pressure / same type / same manufacturer)
- Equipment: SONAPHONE and BS20 with long waveguide
- Trap 1: faulty
- Trap 2: intact
![Steam Trap Inspection: Sound Example 2 | Thermostatic Bimetallic Steam Trap 1 | Defect Steam Trap Inspection: Sound Example 2 | Thermostatic Bimetallic Steam Trap 1 | Defect](/fileadmin/_processed_/1/7/csm_steam_trap_inspection__sound_example_2___thermostatic_bimetallic_steam_trap_1___defect_79449d8cbf.png)
![Steam Trap Inspection: Sound Example 2 | Thermostatic Bimetallic Steam Trap 1 | Working Properly Steam Trap Inspection: Sound Example 2 | Thermostatic Bimetallic Steam Trap 1 | Working Properly](/fileadmin/_processed_/1/7/csm_steam_trap_inspection__sound_example_2___thermostatic_bimetallic_steam_trap_1___working_properly_c461682ffc.png)
Thermodynamic Steam Trap: Faulty | Intact | Example 3
- Comparison of two thermodynamic steam traps (same pressure / same type / same manufacturer)
- Equipment: SONAPHONE and BS20 with long waveguide
- Trap 1: faulty
- Trap 2: intact
![Steam Trap Inspection: Sound Example 3 | Thermodynamic Steam Trap 2 | Defect Steam Trap Inspection: Sound Example 3 | Thermodynamic Steam Trap 2 | Defect](/fileadmin/_processed_/f/0/csm_steam_trap_inspection__sound_example_3___thermodynamic_steam_trap_2___defect_856369226a.png)
![Steam Trap Inspection: Sound Example 3 | Thermodynamic Steam Trap 1 | Working Properly](/fileadmin/_processed_/5/7/csm_steam_trap_inspection__sound_example_3___thermodynamic_steam_trap_1___working_properly_a5316252f2.png)
Thermostatic Steam Trap: Faulty | Intact | Example 4
- Comparison of two thermostatic steam traps (same pressure / same type / same manufacturer)
- Equipment: SONAPHONE and BS20 with long waveguide
- Trap 1: faulty
- Trap 2: intact
![Steam Trap Inspection: Sound Example 4 | Thermostatic Steam Trap 1 | Defect Steam Trap Inspection: Sound Example 4 | Thermostatic Steam Trap 1 | Defect](/fileadmin/_processed_/1/3/csm_steam_trap_inspection__sound_example_4___thermostatic_steam_trap_1___defect_5d3d0969c7.png)
![Steam Trap Inspection: Sound Example 4 | Thermostatic Steam Trap 1 | Working Properly Steam Trap Inspection: Sound Example 4 | Thermostatic Steam Trap 1 | Working Properly](/fileadmin/_processed_/e/4/csm_steam_trap_inspection__sound_example_4___thermostatic_steam_trap_1___working_properly_234e1edab3.png)
